NSE 7 Network Security Architect Real Exam Questions and Answers FREE NSE7_PBC-6.4 Updated on Sep 27, 2022 [Q17-Q34]

4.1/5 - (7 votes)

NSE 7 Network Security Architect NSE7_PBC-6.4 Real Exam Questions and Answers FREE Updated on Sep 27, 2022

NSE7_PBC-6.4 Ultimate Study Guide – PassLeaderVCE

Who can take the Fortinet NSE7_PBC-6.4 certification exam?

You can take the Fortinet NSE7_PBC-6.4 exam only if you are a working professional, and you have a security clearance.
You have to submit the following documents along with your application for the Fortinet NSE7_PBC-6.4 certification exam:

A copy of any required credentials such as security clearance and official letters from employers validating employment history.
An explanation letter about why you want this certification exam; your level of education, work experience and where you find this certification useful.
A copy of your resume.

Fortinet NSE7_PBC-6.4 Exam Objectives

The Fortinet NSE7_PBC-6.4 certification exam has been designed to test your knowledge of the latest technologies in IT security. It tests your knowledge of the networking security fundamentals covered in this certification. The NSE7_PBC-6.4 certification is a three hour long exam and consists of 75 percent objective and 25 percent free time for the preparation. It is very easy to prepare for Fortinet NSE7_PBC-6.4 certification exam in a short period of time. You can easily prepare for this exam with the help of this article.

QUESTION 17
Which two statements about Microsoft Azure network security groups are true? (Choose two.)

Network security groups can be applied to subnets and virtual network interfaces.

Network security groups can be applied to subnets only.

Network security groups are stateless inbound and outbound rules used for traffic filtering.

Network security groups are a stateful inbound and outbound rules used for traffic filtering.

QUESTION 18
You have been asked to secure your organization’s salesforce application that is running on Microsoft Azure, and find an effective method for inspecting shadow IT activities in the organization. After an initial investigation, you find that many users access the salesforce application remotely as well as on-premises.
Your goal is to find a way to get more visibility, control over shadow IT-related activities, and identify any data leaks in the salesforce application.
Which three steps should you take to achieve your goal? (Choose three.)

Deploy and configure FortiCASB with a Fortinet FortiCASB subscription license.

Configure FortiCASB and set up access rights, privileges, and data protection policies.

Use FortiGate, FortiGuard, and FortiAnalyzer solutions.

Deploy and configure FortiCWP with a workload guardian license.

Deploy and configure FortiGate with Security Fabric solutions, and FortiCWP with a storage guardian advance license.

QUESTION 19
When configuring the FortiCASB policy, which three configuration options are available? (Choose three.)

Intrusion prevention policies

Threat protection policies

Data loss prevention policies

Compliance policies

Antivirus policies

QUESTION 20
What is the bandwidth limitation of an Amazon Web Services (AWS) transit gateway VPC attachment?

Up to 1.25 Gbps per attachment

Up to 50 Gbps per attachment

Up to 10 Gbps per attachment

Up to 1 Gbps per attachment

Explanation/Reference: https://d1.awsstatic.com/whitepapers/building-a-scalable-and-secure-multi-vpc-aws-network- infrastructure.pdf (5)

QUESTION 21
You have been asked to develop an Azure Resource Manager infrastructure as a code template for the FortiGate-VM, that can be reused for multiple deployments. The deployment fails, and errors point to the storageAccount name.
Which two are restrictions for a storageAccount name in an Azure Resource Manager template? (Choose two.)

The uniqueString() function must be used.

The storageAccount name must use special characters.

The storageAccount name must be in lowercase.

The storageAccount name must contain between 3 and 24 alphanumeric characters.

QUESTION 22
Which two statements about Amazon Web Services (AWS) networking are correct? (Choose two.)

Proxy ARP entries are disregarded.

802.1q VLAN tags are allowed inside the same virtual private cloud.

AWS DNS reserves the first host IP address of each subnet.

Multicast traffic is not allowed.

QUESTION 23
Refer to the exhibit.

You are configuring an active-passive FortiGate clustering protocol (FGCP) HA configuration in a single availability zone in Amazon Web Services (AWS), using a cloud formation template.
After deploying the template, you notice that the AWS console has IP information listed in the FortiGate VM firewalls in the HA configuration. However, within the configuration of FortiOS, you notice that port1 is using an IP of 10.0.0.13, and port2 is using an IP of 10.0.1.13.
What should you do to correct this issue?

Configure FortiOS to use static IP addresses with the IP addresses reflected in the ENI primary IP address configuration (as per the exhibit).

Delete the deployment and start again. You have in put the wrong parameters during the cloud formation template deployment.

Configure FortiOS to use DHCP so that it will get the correct IP addresses on the ports.

Nothing, in AWS cloud, it is normal for a FortiGate ENI primary IP address to be different than the FortiOS IP address configuration.

QUESTION 24
Your company deploys FortiGate VM devices in high availability (HA) (active-active) mode with Microsoft Azure load balancers using the Microsoft Azure ARM template. Your senior administrator instructs you to connect to one of the FortiGate devices and configure the necessary firewall rules. However, you are not sure now to obtain the correct public IP address of the deployed FortiGate VM and identify the access ports.
How do you obtain the public IP address of the FortiGate VM and identify the correct ports to access the device?

In the configured load balancer, access the inbound NAT rules section.

In the configured load balancer, access the backend pools section.

In the configured load balancer, access the inbound and outbound NAT rules section.

In the configured load balancer, access the health probes section.

QUESTION 25
Refer to the exhibit.

Consider an active-passive HA deployment in Microsoft Azure. The exhibit shows an excerpt from the passive FortiGate-VM node.
If the active FortiGate-VM fails, what are the results of the API calls made by the FortiGate named SSTENTAZFGT-0302? (Choose two.)

SSTENTAZFGT-03-FloatingPIP is assigned to the IP configuration with the name SSTENTAZFGT- 0302-Nic-01, under the network interface SSTENTAZFGT-0302-Nic-01

172.29.32.71 is set as a next hop IP for all routes under FortigateUDR-01

The network interface of the active unit moves to itself

SSTENTAZFGT-03-FloatingPIP public IP is assigned to NIC SSTENTAZFGT-0302-Nic-01

QUESTION 26
You are deploying Amazon Web Services (AWS) GuardDuty to monitor malicious or unauthorized behaviors related to AWS resources. You will also use the Fortinet aws-lambda-guardduty script to translate feeds from AWS GuardDuty findings into a list of malicious IP addresses. FortiGate can then consume this list as an external threat feed.
Which Amazon AWS services must you subscribe to in order to use this feature?

GuardDuty, CloudWatch, S3, Inspector, WAF, and Shield.

GuardDuty, CloudWatch, S3, and DynamoDB.

Inspector, Shield, GuardDuty, S3, and DynamoDB.

WAF, Shield, GuardDuty, S3, and DynamoDB.

QUESTION 27
When an organization deploys a FortiGate-VM in a high availability (HA) (active/active) architecture in Microsoft Azure, they need to determine the default timeout values of the load balancer probes.
In the event of failure, how long will Azure take to mark a FortiGate-VM as unhealthy, considering the default timeout values?

Less than 10 seconds

30 seconds

20 seconds

16 seconds

QUESTION 28
You have previously deployed an Amazon Web Services (AWS) transit virtual private cloud (VPC) with a pair of FortiGate firewalls (VM04 / c4.xlarge) as your security perimeter. You are beginning to see high CPU usage on the FortiGate instances.
Which action will fix this issue?

Convert the c4.xlarge instances to m4.xlarge instances.

Migrate the transit VPNs to new and larger instances (VM08 / c4.2xlarge).

Convert from IPsec tunnels to generic routing encapsulation (GRE) tunnels, for the VPC peering connections.

Convert the transit VPC firewalls into an auto-scaling group and launch additional EC2 instances in that group.

QUESTION 29
Which three properties are configurable Microsoft Azure network security group rule settings? (Choose three.)

Action

Sequence number

Source and destination IP ranges

Destination port ranges

Source port ranges

Explanation/Reference: https://docs.microsoft.com/en-us/azure/virtual-network/network-security-groups-overview

QUESTION 30
Refer to the exhibit.

The exhibit shows a topology where multiple connections from clients to the same FortiGate-VM instance, regardless of the protocol being used, are required.
Which two statements are correct? (Choose two.)

The design shows an active-active FortiGate-VM architecture.

The Cloud Load Balancer Session Affinity setting should be changed to CLIENT_IP.

The design shows an active-passive FortiGate-VM architecture.

The Cloud Load Balancer Session Affinity setting should use the default value.

QUESTION 31
You are deploying Amazon Web Services (AWS) GuardDuty to monitor malicious or unauthorized behaviors related to AWS resources. You will also use the Fortinet aws-lambda-guarddutyscript to translate feeds from AWS GuardDuty findings into a list of malicious IP addresses. FortiGate can then consume this list as an external threat feed.
Which Amazon AWS services must you subscribe to in order to use this feature?

GuardDuty, CloudWatch, S3, Inspector, WAF, and Shield.

GuardDuty, CloudWatch, S3, and DynamoDB.

Inspector, Shield, GuardDuty, S3, and DynamoDB.

WAF, Shield, GuardDuty, S3, and DynamoDB.

Explanation/Reference: https://fortinetweb.s3.amazonaws.com/docs.fortinet.com/v2/attachments/ed901ad2-4424-11e9-
94bf-00505692583a/FortiOS_6.2.0_AWS_Cookbook.pdf

QUESTION 32
Refer to the exhibit.

You are deploying a FortiGate-VM in Microsoft Azure using the PAYG/On-demand licensing model. After you configure the FortiGate-VM, the validation process fails, displaying the error shown in the exhibit.
What caused the validation process to fail?

You selected the incorrect resource group.

You selected the Bring Your Own License (BYOL) licensing mode.

You selected the PAYG/On-demand licensing model, but did not select correct virtual machine size.

You selected the PAYG/On-demand licensing model, but did not associate a valid Azure subscription.

QUESTION 33
Refer to the exhibit.

A customer has deployed an environment in Amazon Web Services (AWS) and is now trying to send outbound traffic from the Web servers to the Internet. The FortiGate policies are configured to allow all outbound traffic; however, the traffic is not reaching the FortiGate internal interface.
What are two possible reasons for this behavior? (Choose two.)
